标准的ILS进样针接头
| O.D. mm | 长度 mm | 针 头 | 货号5 ul syringes (3-pack) | 货号10 ul syringes (3-pack) | 货号25-100 ul syringes (3-pack) | 货号25o ul - 10 ml syringes (3-pack) |
| 0.47 | 42 | a | 2865308 | 2865408 | ||
| 0.47 | 42 | c | 2834307 | 2834407 | ||
| 0.47 | 51 | a | 2832301 | 2832401 | ||
| 0.47 | 51 | b | 2832302 | 2832402 | ||
| 0.47 | 51 | c | 2832303 | 2832403 | ||
| 0.47 | 51 | d | 2832304 | 2832404 | ||
| 0.55 | 51 | a | 2831013 | 2841013 | ||
| 0.55 | 51 | b | 2831014 | 2841014 | ||
| 0.55 | 51 | d | 2831015 | 2841015 | ||
| 0.64/0.47 | 42 | c | 2834308 | 2834408 | ||
| 0.64 | 42 | c | 2834309 | 2834409 | ||
| 0.72 | 51 | a | 2832501 | 2832601 | ||
| 0.72 | 51 | c | 2832503 | 2832603 | ||
| 0.72 | 51 | d | 2832504 | 2832604 | ||
| 0.90 | 51 | a | 2831023 | |||
| 1.10 | 51 | a | 2831027 | |||
| 2.00 | 51 | a | 2831029 |
HP 7670 -7672 GC 自动进样器注射器
| O.D. mm | 长度 mm | 针 头 | 货号5 ul syringes (3-pack) | 货号10 ul syringes (3-pack) | 货号25-100 ul syringes (3-pack) | 货号25o ul - 10 ml syringes (3-pack) |
| 0.47 | 51 | a | 2860307 | 2860407 |
Waters HPLC 注射器
| O.D. mm | 长度 mm | 针 头 | 货号5 ul syringes (3-pack) | 货号10 ul syringes (3-pack) | 货号25-100 ul syringes (3-pack) | 货号25o ul - 10 ml syringes (3-pack) |
| 0.50 | 50 | b | 2832306 | 2832406 | 2832506 | 2842606 |
Valco VISF-1 HPLC 注射器
| O.D. mm | 长度 mm | 针 头 | 货号5 ul syringes (3-pack) | 货号10 ul syringes (3-pack) | 货号25-100 ul syringes (3-pack) | 货号25o ul - 10 ml syringes (3-pack) |
| 0.72 | 19 | b | 2833305 | 2833405 | 2833505 |
Rheodyne HPLC 注射器
| O.D. mm | 长度 mm | 针 头 | 货号5 ul syringes (3-pack) | 货号10 ul syringes (3-pack) | 货号25-100 ul syringes (3-pack) | 货号25o ul - 10 ml syringes (3-pack) |
| 0.72 | 51 | b | 2831305 | 2831405 | 2831505 | 2832602 |
Hamilton注射器
| O.D. mm | 长度 mm | 针 头 | 货号5 ul syringes (3-pack) | 货号10 ul syringes (3-pack) | 货号25-100 ul syringes (3-pack) | 货号25o ul - 10 ml syringes (3-pack) |
| 0.50 | 50 | b | 21080426 | |||
| 0.47 | 51 | a | 21775802 | |||
| 0.72 | 51 | a | 21777003 | 21777901 | ||
| 0.72 | 51 | b | 21777001 |
