需要跟如下的固定圆环配套使用
|
螺纹 |
管的直径 |
货号 |
|
|
|
10 Pack |
|
M6 |
3.2 mm (1/8") |
4130005 |
|
1/4"-28 |
3.2 mm (1/8") |
4130020 |
|
M6 |
1.6 mm (1/16") |
4130016 |
|
1/4"x28 |
1.6 mm (1/16") |
4130019 |
|
M6 |
2.7 mm |
4130004 |
|
1/4"-28 |
2.7 mm |
4130025 |
|
和上面的法兰接头配套使用
|
管的直径 |
货号 |
|
ID |
10 Pack |
|
1.6mm |
4132016 |
|
2.7mm |
4132031 |
|
3.2mm |
4132032 |
|
|
描述 |
for Tubing with Thread |
O.D. |
材料 |
货号 |
|
|
|
|
|
10 Pack |
|
Fitting |
1/4"-28UNF |
3.2 mm (1/8") |
PP |
4130045 |
|
Fitting |
1/4"-28UNF |
3.2 mm (1/8") |
PEEK |
4130083 |
|
Fitting |
1/4"-28UNF |
1.6 mm (1/16") |
PP |
4130066 |
|
Fitting |
1/4"-28UNF |
1.6 mm (1/16") |
PEEK |
4130079 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Ferrule |
- |
3.2 mm (1/8") |
PTFE |
4130060 |
|
Ferrule |
- |
3.2 mm (1/8") |
PEEK |
4130065 |
|
Ferrule |
- |
1.6 mm (1/16") |
PTFE |
4130058 |
|
Ferrule |
- |
1.6 mm (1/16") |
PEEK |
4130048 |
|
|
描述 |
螺纹 |
Tubing O.D. |
材料 |
货号 |
|
|
|
|
|
|
|
HPLC Fitting |
10-32UNF |
1.6 mm (1/16") |
PEEK |
4130080 |
|
HPLC Fitting Spanner Flat |
10-32UNF |
1.6 mm (1/16") |
PEEK |
4130081 |
|
|
螺纹 |
连接材料
|
O.D. |
货号 |
|
|
|
|
|
|
1/4"-28UNF |
Polypropylene (PP) |
3mm |
4130024 |
|
M6 |
Polypropylene (PP) |
3mm |
4130023 |
|
螺纹 |
连接材料 |
O.D. |
货号 |
|
|
|
|
|
|
1/4"-28UNF |
PEEK |
3mm |
2702226 |
|
|
描述 |
螺纹 |
材料 |
I.D. |
货号 |
|
|
|
|
|
|
|
Fitting Short |
G 1/8 |
PEEK |
3.2 mm |
41006990 |
|
Fitting Long |
G 1/8 |
PEEK |
3.2 mm |
41007175 |
|
|
设置尺寸 |
描述 |
货号 |
|
|
|
|
|
3.2x1.6 |
tubing 3.2x1.6 + fitting M6 + washer |
4133032 |
|
3.2x1.6 |
tubing 3.2x1.6 + fitting 1/4"-28UNF + washer |
4133033 |
|
1.6x0.8 |
tubing 1.6x0.8 + fitting M6 + washer |
4133168 |
|
1.6x0.8 |
tubing 1.6x0.8 + fitting 1/4"-28UNF + washer |
4133169 |
|
1.6x0.5 |
tubing 1.6x0.5 + fitting M6 + washer |
4133165 |
|
1.6x0.5 |
tubing 1.6x0.5 + fitting 1/4"-28UNF + washer |
4133166 |
|
|
螺纹 |
货号 |
|
|
10 Pack |
|
M6 |
4130021 |
|
1/4"-28UNF |
4130022 |
|
.jpg)
|
螺纹 |
货号 |
|
|
10 Pack |
|
Luer |
2702206 |
|
|
|
|
注射器引导器不锈钢制品，阳极氧化铝 |
|
 |
|
货号： |
2700001 |
|
|
|
|
|
|
|
|
 可以放置3个注射器的架子货号2700002 |
|
 可以放置8根注射器的架子 |
|
|
|
描述 |
O.D. |
I.D. |
壁厚 |
材料 |
货号 |
|
|
|
|
|
|
2 Pack |
|
Washer |
5.2mm |
1.9mm |
0.9mm |
PTFE |
4132033 |
|
Washer |
5.2mm |
2.4mm |
0.9mm |
PTFE |
4132035 |
|
|
|
|
|
